Technical Features





The Omsider is an amphibian microlight, produced in the Czech Republic by ATEC. The plane is built in full composite, is easy to fly and has gentle flying characteristics.





FLIGHT CHARACTERISTICS

(ROTAX 912 ULS, 100 HP)

G-limits +4g / -2g

Stall speed 64 km/h / 35 kt

Min. no-flap speed 85 km/h / 46 kt

Cruising speed 175 km/h / 95 kt

Mx. level speed 195 km/h / 105kt

Never exceed speed 210 km/h / 114 kt

Rate of climb 4 m/s / 800 ft/min

Fuel consumption (150/180 km/h) 14/18 L/h

SPECIFICATIONS

Wing span 9,2 m

Tail span 2,4 m

Length 6,8 m

Height 2 m

Wing area 10,1 m2

Empty weight 330 kg

Payload 270 kg

Max. take-off weight  600 kg

Fuel capacity 2x 50 L




More information from ATEC on their website
